Efficient collaboration | Dare to take responsibility - Latest construction progress of ETFE Air pillow Corridor skycurtain project in Bodotson Valley, Hangzhou

Recently, the latest progress of Hangzhou Bodosen Valley ETFE air pillow corridor sky curtain project was exposed. From the construction site, the skylight steel structure has been welded and assembled, the paint part has also been painted, and the membrane tension installation stage is being carried out.

Project introduction

Hangzhou Bodosen Valley is an industrial park built with "milk tea" as its main business. The tall buildings are located in the square in the form of surrounding and encircling. The sky curtain is made in the atrium area of the four tall buildings, which will be used as a commercial roof in the future. The sky curtain takes tea mountain as the theme, and has the unique peaks and valleys of tea mountain, which are superimposed and scattered, and the valleys stretch and bend, just like the river towns of Jiangnan.

The ceiling shape is particularly complex, the span is large, the elevation of each point of the truss is different, and the node structure is complex, the cross section is diverse, the structure installation area is large, the construction work is wide, and the overall curved layout, the installation of steel structure truss is carried out at high altitude, the installation precision is high, in the steel film structure industry, and even in the national construction industry, it is a particularly complex project. At the top and bottom, there are three different colors of film material layer upon layer, layer upon layer, layer upon layer coating, and the film nodes are overlapping and sharing with each other, which is the highlight and feature of this project, but also the difficulty. The same node may install two different kinds of film, and the film between the film and the formation of different penetration, different heights between the tea peaks, rolling. The overall appearance is magnificent, which can be used as a classic project for other project schemes.

Construction progress

The camera turns to the project membrane structure construction site, which is very busy on the site. According to the feedback from the project manager, the ETFE membrane installation work has been carried out at present, and the membrane body is being tensioned step by step, and a large area of the membrane structure is being installed.

Hangzhou Bodosen Valley ETFE air tie corridor sky curtain project as a key project of the company, the project has been widely concerned since the undertaking, from the foundation embedment, steel column lifting splicing, to the overall successful completion of the steel structure truss, and then to today's membrane structure tension installation task, fully show our Wanhao people a high degree of responsibility, with practical actions to prove that we Wanhao people "not afraid of difficulties, Face up to difficulties, can fight hard, dare to fight hard, good at fighting "fine style. Wanhao Space Structure will continue to uphold the idea of doing high-quality engineering and contribute to the development of steel membrane structure construction.

We will continue to take responsibility, collaborate efficiently, control the project progress in real time, and present a satisfactory answer for "quality and quantity delivery"!
