Good news! Congratulations to Wanhao Space Structure for winning the 2024 Technology Innovation Award from the China Steel Structure Association

On October 21-22, the 40th anniversary of the establishment of the China Steel Structure Association and the 2024 China Steel Structure Conference was held in Beijing. The meeting held in commemoration of the 40th anniversary of the establishment of the China Steel Structure Association award, the China Steel Structure Association science and Technology Progress award, technology innovation award. The "Key Technology of ETFE membrane Design and Construction of Love Tower of Xi 'an Silk Road Style City" completed by Wanhao Space Structure won the 2024 Technology Innovation Award.

It is understood that the application criteria of the technological innovation award need to be evaluated by the scientific and technological achievements of the provincial (ministry, industry), autonomous regions, municipalities directly under the Central Government, and associations, and applied to practice for more than one year, complete and apply innovative technological achievements in the field of steel structure, outstanding technological innovation, advanced technical and economic indicators, and achieve economic benefits, social benefits, and ecological and environmental benefits. It has made great contributions to promoting the application of steel structure construction.

Project overview

Xi 'an Silk Road-Tower of Love consists of four parts: tower body, streamer, skirt and Mobius ring. The tower body is composed of a two-way rhomboid mesh interwoven combination, the spiral hyperbolic streamers rotate upward from the tower body and diverge, and the exterior is covered with ETFE cable membrane structure, and the shape rises and spirals upward. The skirt is arranged radially by the hyperboloid truss, and the cornice of the truss is composed of a combination of musical notes, and the whole is covered with ETFE cable membrane structure. The top is closed with a complex Mobius ring shape, and the surface is mounted with a dynamic LED screen. The following is a complete overview of the construction and installation process of the steel film structure.

Function and art are equal, creating dancers of the night

The main light show of the Silk Road Tower is presented in three parts: ribbon, skirt and Mobius ring. In order to better effect, the Happy World of the Silk Road chooses to image in an irregular area and enhance the display effect by presenting in a ribbon. It seems that each has its own characteristics, but it is a unified one. While the lighting is beautiful, it is accompanied by music, and the four seasons chapters made by digging the rhythm of the four seasons are played from the tower in a scattering way, surrounding the whole tower and the tower, and also the Silk Road culture runs through the light show.

As a space carrier integrating landmark, landscape, history and human collection, the Silk Road-Tower of Love is not a single performance of the paradise value, but a more diversified externalization of the spiritual core of the building.

In recent years, based on professional characteristics and advantages,Wanhao has strengthened the awareness of strong enterprise in science and technology, adhered to the basic idea of "focusing on scientific research, innovating business formats, expanding regulations and increasing efficiency, and benefiting employees", and gathered innovative resources, innovative strength, and innovative advantages. In the future, Wanhao will continue to fully implement the concept of innovative development, maintain the quality of academic achievements, continue to improve scientific research and innovation capabilities, and provide strong scientific and technological support for promoting high-quality development of enterprises.
