Little knowledge about membrane structure design/sustainable design concept of membrane structure

Dec. 30, 2021
Share

To make a membrane structure building with superior performance and qualified quality, it is inseparable from the designer's meticulous design. There are some regulations in the design of membrane structure. How much do you know? This article will give you a brief introduction to the "small knowledge about membrane structure design regulations" so that you can have an understanding of this. Please follow the Wanhao Space Structure to take a look.

① In addition to meeting the architectural and planning requirements, the architectural shape of the membrane structure should also be determined by the shape of the membrane structure.

②. Membrane materials should be selected according to the building's fire protection rating and fire protection requirements.

③The design of membrane structure building fire protection umbrellas should be combined with the characteristics of membrane structure in accordance with the relevant regulations in the current national standard "Code for Design of Building Fire Protection" (GBJ16), with smoke detection devices, fire alarm devices, fire hydrants and automatic sprinkler equipment.

④ The drainage system of membrane structure should be designed according to the conditions of building shape, structure shape, production and installation, etc., to ensure smooth drainage and no accumulation of water.

⑤ The membrane structure should be designed for node waterproofing according to the waterproofing requirements of the building. The exposed fasteners should be made of stainless steel, aluminum alloy or galvanized steel.

⑥. The connection of the diaphragm should maintain a high degree of water tightness, and an anti-peeling test should be carried out. The diaphragms should be arranged in a tile-like shape, and the lower diaphragms should be covered by the higher diaphragms.

⑦. Membrane structure may improve structural thermal insulation requirements by adding membrane liners or thermal insulation layers. For buildings with special thermal insulation and thermal insulation requirements, double-layer membrane materials should be used.

⑧. The influence of the membrane material on the acoustic environment of the building should be considered when designing the membrane structure.

Little knowledge about membrane structure design/sustainable design concept of membrane structure

Wanhao's design department was established to provide our customers with advanced design capabilities. It uses sophisticated 3D/CAD rendering and animation software to develop cutting-edge architectural renderings. "We hope to deliver high-quality products to customers within the specified time. Therefore, CAD software must have professional functions to improve drawing efficiency, and at the same time, it must accurately convert creative designs into engineering drawings used to guide workshop production. So as to shorten the production cycle. The design department is a supplement to our continuous innovation and creativity. Our design team is composed of industrial designers and architects, who understand the basic principles of shape, form and function; their creativity and technical ability make Clients can have unique insights into the concept of a 3D version suitable for architecture.

Animations expressed in CAD format usually represent actual products and final products, and are the starting point for translating concepts into reality. The design department also plays an important role in preparing three-dimensional models of structures for engineering analysis. This model allows our sales engineering department to perform preliminary engineering analysis and determine whether the structure is stable, the shape of the membrane is correct, and whether there is excessive stress or whether it is in a pond location.

Finally, it provides our estimation department with sufficient information about the size and weight of the components, resulting in a cost-effective estimate in our proposal. The Wanhao Design Department differentiates us from our competitors by providing the company with advantages and customer advantages.

Little knowledge about membrane structure design/sustainable design concept of membrane structure

Sustainable design

With sustainable design becoming one of the most important issues in today's construction industry, designers not only pay attention to environmentally friendly materials, but also introduce customers to new design techniques, the use of materials, and construction methods that meet "green" standards.

Nowadays, with the rapid use of materials, we are increasingly seeking greening and environmental protection. People are more yearning for a "green" and "low-carbon" lifestyle. Membrane structure buildings are used as energy-saving buildings, green buildings, and low-carbon ecological communities. The concept of Hecheng is gradually established and popularized to be deeply rooted in the hearts of the people.
