WanhaoSpatial Structure staff to the University of Nottingham Ningbo outdoor sports film structure project learning exchange

In order to better serve the front-line construction personnel, strengthen the coordination among various departments of the company, and deepen the understanding of the company's business and construction projects, on July 30th, Wanhao Spatial Structure organized the staff to study and visit the outdoor sports film structure project of the University of Nottingham Ningbo, which was built by our company.

Before entering the operation site, the project leader shall make safety disclosure to the relevant personnel.

After entering the construction site, the project department head first extended a warm welcome to colleagues, then introduce the general situation of the engineering project department, internal management, organizational structure, external coordination, and the next phase of the important and difficult work, to visit the operation and management of the project department staff have a more comprehensive and in-depth understanding.

The structure of the basketball court and tennis court is a spatial composite steel arch system. Each pin consists of three arc-shaped steel pipes rooted from the ground as the main bearing rod, and the supporting rod is connected in the middle.

The basketball court is 114m long and 40m wide. It is composed of seven trusses of shuttle curved surfaces connected, with a maximum span of 40m and a maximum arc elevation of 11.5m. The tennis court is 92.5m long and 39m wide. It is composed of six trusses of shuttle-shaped curved surfaces connected, with a maximum span of 39m and a maximum arc elevation of 12.5m.

Then the project leader took you to visit the construction site, combined with the site construction to introduce some professional knowledge of the project.

In order to avoid stress concentration and ensure structural safety, the three rod parts of the column foot were welded into a whole in the factory for hoisting, and then connected with the joint rod parts on site.

Visit colleagues listen carefully to the related personnel to explain in detail the technological process, carefully recorded, feeling as Wanhao the pride and proud, also feeling the hardships of the construction site and is not easy, you have said, in the future work a lot more to learn, to improve their professional skills, to grow into an excellent Wanhao, For the company to maintain sustained, stable and healthy development of their own contribution.
